Mean Well UHP-1000 slim type with PFC switching power supply
- Buy 8 for £198.58 each and save 3%
- Buy 96 for £187.41 each and save 8%
Made in China with 5 years warranty, genuine version, high quality, not cheap copycat
We are the distributor of Mean Well products, directly from factory, good price
Click here to know more detailed information about Mean Well UHP-1000 switching power supply
Mean Well UHP-1000-12 is default version, UHP-1000-24, UHP-1000-36, UHP-1000-48 is optional
Feature
Slim and Low profile (41mm)
Fanless and conduction-cooled design
Withstand 300VAC surge input for 5 seconds
Built-in active PFC function
-30~+70°C working temperature
Output voltage and constant current level programmable
Protections: Short circuit / Overload / Over voltage / Over temperature
Built-in remote ON-OFF control
DC OK active signal
Operating altitude up to 5000 meter
LED indicator for power on
5 years warranty
Certificates
Safety: UL/EN62368-1EMC: EN 55032 / 55024
Applications
Industrial automation machinery
Industrial control system
Mechanical and electrical equipment
Electronic instruments, equipmentor apparatus
Test and measurement instrument
Laser related machine
Charging related equipment
Household appliances
Description
UHP-1000 series is a 1000W single-output slim type power supply with 41mm of low profile design. Adopting the full range 90~264VAC input, the entire series provides an output voltage line of 12V, 24V, 36V and 48V. In addition to the high efficiency up to 96%, that the whole series operates from -30°C~ 70°C under air convection without fan. UHP-1000 has the complete protection functions and 5G anti-vibration capability; It is complied with the international safety regulations such as TUV EN62368-1, UL62368-1, and the design refers to EN61558-1 and EN60335-1. UHP-1000 series serves as a high performance power supply solution for various industrial applications.
